JEEP
Gladiator
2020 - Present
BASE MODEL: JLU Wrangler
ASSEMBLY: Toledo, OH, USA
UNITS PRODUCED: Unknown
JT
The JT Gladiator has the same front end as the JLU Wrangler but with a longer wheelbase and pickup-truck bed behind. It is closely related to the CJ-8 Scrambler, which was a pickup-truck version of the CJ-7 before it.
JEEP JT SPECS
MAIN SPECS
OVERALL LENGTH (OL): 218.0
OVERALL WIDTH (OW): 73.7
OVERALL HEIGHT (OH), HARD TOP: 73.6
OVERALL HEIGHT (OH), FRAME: 70.9
WHEELBASE (WB): 137.3
TRACK WIDTH (TR): 64.4
CURB WEIGHT (CW): 5,050 lbs
WINDSHIELD ANGLE (WA): 35°
CHASSIS SPECS
GROUND CLEARANCE (GC): 11.1
APPROACH ANGLE (AA): 44°
BREAKOVER ANGLE (BA): 18°
DEPARTURE ANGLE (DA): 26°
SUSPENSION TYPE (SU): Coil Spring
WHEEL SPECS
WHEEL NAME: Extreme Recon Wheel
WHEEL DIAMETER (WD): 17.0
WHEEL WIDTH (WW): 8.0
BOLT PATTERN (BP): 5 x 5
TIRE WIDTH (TW): 11.2
TIRE DIAMETER (TD): 32.7
SPARE LOCATION: Spare Under Bed
All specifications refer to original stock versions
All dimensions shown in inches
Drawn by Christopher James Botham
